Specification parameters

Model: W157AY/W236AY
<— Slide the table left and right —>
Model15.7inchW236AY
Screen Size15.7inch23.6inch
Android CPU

RK3568, Four core, with a maximum frequency of 2.0GHz

RK3288, Four core, with a maximum frequency of 1.8GHz

Operation SystemAndroid  11Android  7.1
RAM2GB2GB
NAND Flash32GB32GB
NetworkWIFI, LANWIFI, LAN
Resolution960x9601280x1280
Display Size (mm)

Diameter：400

Diameter：599

Product Size (mm)

Diameter：453 x 55.8(D)

Diameter：657 x 50.85(D)

Brightness700 cd/m2700 cd/m2
response time8ms8ms
Colors16.7M16.7M
Viewing Angle17801780
Contrast Ratio1200:11200:1
Input VoltageAC 90-240 V (50Hz-60Hz)AC 90-240 V (50Hz-60Hz)
timing functionadjuvantadjuvant
Speakers8Ω, 2W8Ω, 2W
Working Temperature0℃ ~ 40℃0℃ ~ 40℃
AccessoriesRemote Control, Power Cable, WIFI AntennaRemote Control, Power Cable, WIFI Antenna
